1300 Series Mortise Cylinder Panic Exit Device

1300 Series Mortise Cylinder Panic Exit Device

Description:
1300 series mortise panic exit device, equipped with a mortise lock, is suitable for wooden and metal doors. This mortise lock exit device with attractive style is designed for commercial building, hospital and public building. The series mortise panic exit device composes of latch bolt, body and press rod. Slight pressure on the panic exit hardware touch bar will retract latch for exit. 1300 series mortise panic exit device can be optimized for use with Oubao door closer.

Properties of 1300 Series Mortise Panic Exit Device:
DK1300:
1.This mortise lock exit device is easy to install on wooden, hollow steel or aluminum doors.
2.It fits to mortise lock body, rim type and press style bar.
3.This non-handed mortise panic exit device can be used for left hand door or right hand door.
4.It is configured with standard oval shaped horizontal bar, and the length is 900mm, the max can reach 1300mm on request.
5.The standard square spindle of this mortise panic exit device is 8×8, 9×9 is also available.

DK1310:
1. This mortise lock exit device has a lateral lock point, and power metal or Zinc latch swing latch.
2. This non-handed exit device fits to both left hand and right hand doors.
3. The mortise panic exit device adopts a standard oval shape horizontal bar with 900 mm. Its max length can reach 1300 mm on request.
4. The mortise lock exit device can offer assembly instructions and installation template for users.

DK1320:
1. This non-handed exit device fits to both left hand and right hand doors.
2. This vertical type mortise panic exit device is designed with two locking points and equipped with upper and tower locking device.
3. Stan It is configured with standard oval shaped horizontal bar, and the length is 900mm, the max can reach 1300mm on request.
4. The mortise lock exit device can offer assembly instructions and installation template for users.

Notice:
1.Tighten the screws two months after the panic exit hardware being installed;
2.Do not install the mortise panic exit device in the open air, or it well easily get rusty.

Packaging and Transportation:
1.One piece in an inner box, eight inner boxes in one carton;
2.Transport by sea or by air.

Oubao Security Technology Co., Ltd. specializes in manufacturing door closers and mortise panic exit device in China. With registered capital of 55.8 million RMB, we offer a broad line of security protection products, including door closer, fingerprint lock, panic bar, mortise lock exit device and intelligent lock. We export our security protection products like mortise panic exit device to American, Europe, Southeast Asia, Middle-East, Africa and Oceania. We also resort to strict outsourcing supervision to guarantee the superior quality. We have gained the qualification of independent third party testing.

.
